Introduction
TD75 universal fixed belt conveyor is widely used in metallurgy, coal, transport, water and electricity for conveying of bulk materials or packed products with advantages of large conveying capacity, simple in structure, convenient maintenance, low cost, strong generality, etc., it can convey with one conveyor, multiple conveyors or form horizontal or inclined conveying system with other conveyors according to requirements of conveying process.
TD75 universal fixed belt conveyor is widely used in metallurgy, coal, transport, water and electricity for conveying of bulk materials or packed products with advantages of large conveying capacity, simple in structure, convenient maintenance, low cost, strong generality, etc., it can convey with one conveyor, multiple conveyors or form horizontal or inclined conveying system with other conveyors according to requirements of conveying process.
| Main technical parameters： | ||||||||||||
| Broadband | tape speed V m/s | |||||||||||
| (㎜) | 0.8 | 1.0 | 1.25 | 1.6 | 2.0 | 2.5 | 3.15 | 4(4.5) | 5.0(5.6) | 6.5 | ||
| delivery value IV,㎥/h | ||||||||||||
| 500 | 69 | 87 | 108 | 139 | 174 | 217 | ||||||
| 650 | 127 | 159 | 198 | 254 | 318 | 397 | ||||||
| 800 | 198 | 248 | 310 | 397 | 496 | 620 | 781 | |||||
| 1000 | 324 | 405 | 507 | 649 | 811 | 1014 | 1278 | 1622 | ||||
| 1200 | 593 | 742 | 951 | 1188 | 1486 | 1872 | 2377 | 2674 | 2971 | |||
| 1400 | 825 | 1032 | 1321 | 1652 | 2065 | 2602 | 3304 | 3718 | 4130 | |||
| 1600 | 2186 | 2733 | 3444 | 4373 | 4920 | 5466 | 6122 | |||||
| 1800 | 2795 | 3494 | 4403 | 5591 | 6291 | 6989 | 7829 | 9083 | ||||
| 2000 | 3470 | 4338 | 5466 | 6941 | 7808 | 8676 | 9717 | 11277 | ||||
| 2200 | 6843 | 8690 | 9776 | 10863 | 12166 | 14120 | ||||||
| 2400 | 8289 | 10526 | 11842 | 13158 | 14737 | 17104 | ||||||
